Product Model
G100E-LRF
Add comparison
Cancel comparison
Slide to display more
Display
Fold up
Expand
Display Size
10.1
Display Area (mm)
222.72(H)×125.28(V)
Resolution
1024*600
Display Colors
16.2 million
Viewing Angle
-
Contrast Ratio
500:1
Backlight
LED
Brightness (cd/m²)
300
Backlight Life
>30000 hours
Touch Panel
Fold up
Expand
Touch Panel
4-wire precision resistive network
Processor
Fold up
Expand
CPU
ARM RISC32Bit 792MHz
GPU
-
NPU
-
Memory
Fold up
Expand
RAM
128M
Flash Memory
256M
Interfaces
Fold up
Expand
USB Host
1
USB Slave
1
Ethernet
1
Communication Port
COM0:RS232/RS485;
COM2:RS232
4G
-
Wi-Fi
-
Audio Interface
-
Other Interfaces
-
HDMI
-
RFID
-
Programmable Keys
-
Selector Switch
-
Emergenccy Stop
-
Grip Switch
-
LED Indicator
-
Electrical
Fold up
Expand
Input Power
DC10V-28V
Power Consumption
6W@24VDC
Allowable Power Loss Time
<3ms
Insulation Resistance
>50 MΩ @ 500V DC
Voltage Endurance
500V AC 1minute
Mechanical
Fold up
Expand
Enclosure
Engineering plastic
Dimensions (mm)
271x191x36(mm)
Panel Cut-out (mm)
260x 180(mm)
Mounting
Panel mounting & Bracket mounting
Cable
-
Mounting Accessories
-
Environmental
Fold up
Expand
Operating Temperature
0~50°C
Operating Humidity
10~90%RH (Non-condensing)
Storage Temperature
-20~60°C
Storage Humidity
10~90%RH (Non-condensing)
Vibration Resistance
10~500Hz, 30m/s², X, Y, Z direction/hour
Cooling
Natural air cooling
Protection
Fold up
Expand
Power Isolation
Built-in
Serial Port Isolation
-
PCB Coating
-
Degree of Protection
Front panel: IP65
Certifications
Fold up
Expand
CE Certificate
EN61000-6-4:2019，EN61000-6-2:2019
UL Certificate
-
Software
Fold up
Expand
Configuration Software
Kinco DTools
Remote Maintenance Platform
EdgeAccess1.0
